GARRETT 836026-5005S TURBOCHARGER GT2860R TRIM 62 A/R 0.60

Ball bearing

Oil & Water cooled bearign system

T25 turbine inlet flange with threaded bolt holes instead of traditional through holes.

Turbine housing has a unique "compact" 5-bolt outlet that is not interchangeable with traditional T25 5-bolt outlets.

Turbine housing is cast from high-nickel "Ni-Resist" material for extreme applications.

Turbine wheel is cast from "Inconel" material for extreme applications.

Direct replacement upgrade turbocharger for GT2556R (702987-0007) used on Nissan Skyline R34 GT-R.

Great size for applications w/packing constrains.

Ideal for smaller displacement engines making up to 360 Hp.

Turbine housing option available

• Turbo Part Number | Model | Turbine side | Compressor side
• New Part | Old Part | O.D.mm | I.D.mm | TRIM | A/R | O.D.mm | I.D.mm | TRIM | A/R
• 836026-5005S | 707160-5005S | GT2860R | 53.8 | 47.0 | 76 | .64 | 60.0 | 47.0 | 62 | .60

HORSEPOWER 350HP - 360HP

DISPLACEMENT 1.8L - 3.0L

C.H.R.A. Part Number

• New Part CHRA | Old Part CHRA
• 835998-5006S | 446179-5051S

Applicable Garrett P/N's:

707160-0005

GT2860R

446179-0051

707160-5
707160-05
707160-5005S

836026-5
836026-5005
836026-05
836026-5005S

Product category: Turbocharger
