GARRETT 836028-5002S TURBOCHARGER GT3071R W/O HOUSING KIT

Ball bearing.

Oil & Water cooled bearign system.

• Turbo Part Number | Model | Turbine side | Compressor side
• New Part | Old Part | O.D.mm | I.D.mm | TRIM | A/R | O.D.mm | I.D.mm | TRIM | A/R
• 836028-5002S | GT3071R | 60.0 | 55.0 | 84 | w/t | 71.0 | 53.1 | 56 | .50

HORSEPOWER 310HP - 475HP

DISPLACEMENT 1.8L - 3.0L

TURBINE HOUSING OPTIONS (O/V T3 / 4-Bolted )

• PART NUMBER | A/R | TYPE
• 740902-0003 | 0.63 | Free Float
• 740902-0002 | 0.82 | Free Float
• 740902-0001 | 1.06 | Free Float
• TURBINE HOUSING OPTIONS (O/V T3 / V-Band)
• PART NUMBER | A/R | TYPE
• 740902-0009 | 0.63 | Free Float
• 740902-0008 | 0.82 | Free Float
• 740902-0007 | 1.06 | Free Float
• TURBINE HOUSING OPTIONS Hi Sil (O/V T4 / V-Band )
• PART NUMBER | A/R | TYPE
• 740902-0015 | 0.63 | Free Float
• 740902-0014 | 0.82 | Free Float
• 740902-0013 | 1.06 | Free Float
• TURBINE HOUSING OPTIONS Ni-Resist ( Div V-Band / V-Band)
• PART NUMBER | A/R | TYPE
• 740902-0024 | 0.61 | Free Float
• 740902-0023 | 0.83 | Free Float
• 740902-0022 | 1.01 | Free Float
• TURBINE HOUSING OPTIONS Ni-Resist ( Div T3 / V-Band )
• PART NUMBER | A/R | TYPE
• 740902-0030 | 0.61 | Free Float
• 740902-0029 | 0.83 | Free Float
• 740902-0028 | 1.01 | Free Float
• TURBINE HOUSING OPTIONS Ni-Resist ( V-Band / V-Band)
• PART NUMBER | A/R | TYPE
• 740902-0036 | 0.61 | Free Float
• 740902-0035 | 0.83 | Free Float
• 740902-0034 | 1.01 | Free Float
